Arts & Crafts Lever Passage Leverset

Heavy Duty Solid Brass Single Cylinder Leverset with Arts and Crafts Lever Passage Leverset

Emtek's passage leversets use traditional American latches complete with a variety of trim styles, handcrafted from authentic materials. The knobset is operated by a knob from both the interior and exterior. With the passage function, the door does not lock from either side. Uncompromisingly rugged and beautifully crafted, these locks are suitable for the very finest homes.

The Arts & Crafts Collection's knob / lever handles are supported by springs mounted behind the rosettes and sideplates, which return the handles back to the rest position and prevent lever sag. The latches are heavy-duty die cast construction, with strong internal springs, solid brass nose bolts, and sintered metal cams. A plastic bushing located in the joint between the handle and the rosette ensures a friction-free wear surface, preventing metal from bearing on metal and providing smooth, long-lasting operation. Handles are positively connected to rosettes with a permanent clip. Each has a set screw which eliminates "handle wobble" when tightened. Emtek's threaded tubes are machined brass to ensure good threads and prevent corrosion


Passage Set

Door Thickness: 1 3/8" or 1 3/4" (please specify)
Backset: 2-3/8" or 2-3/4"For detailed information on all options please click on "view specs"Latch Type

1/4" Radius Corners
Square CornersBackset Option

Standard 2 3/8"
2 3/4"Handing Option

Left

Right
Rectangular Rosette - 5105
Hammered Rosette - 5106
